portable incinerator manufacturers


Tanque

Capacidade mínima: 500L

Provido de estrutura de suporte

Válvulas

Indicador de nível de tanque

Funil

Filtro de impurezas na boca do tanque





comprising of, as a minimum, electronic ignition and all necessary interlocks and safety devices to provide safe



operation. The chamber and burner shall be designed to maintain a minimum combustion temperature of at least



930 to 980 C (1700 to 1800 F), but shall not to exceed 1150 C (2100 F). The ash-removal system shall consist of, as



a minimum, the direct manual removal into a dry



Cyclone air filters shall be provided to remove the larger particulates. Cyclone air separators may be provided with



powered fans to increase the velocity of the gases inside the cyclone to improve the collection efficiency for smaller



particles.



5.16.2 MEDICAL WASTE INCINERATORS



Medical waste incinerators shall be specifically designed by the manufacturer to dispose of all medical wastes. All

units shall be designed for 8 hours



per day of continuous operation and be rated in quantity per hour (i.e. kg/hr or lbs/hr).



Incinerator loading or charging of medical waste shall be batched-fed manually.



Primary combustion chamber shall be the stationary fixed-hearth (or kiln), multiple-chamber, retort type or larger



capacity rotary-hearth (or kiln) type. Burner and combustion air controls shall be fully automatic comprising of, as a



minimum, electronic ignition and all necessary interlocks and safety devices to provide safe operation. The


Pet Cremation Equipment


Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:CLOVER
Origin:Cn
Production Capacity:1000 Sets Per Year

Product Description

We supply incinerator and also burners. Some model of incinerator use Italy original burner (gas or oil fuel) and some model use China original burner. Generally, incinerator with two burners but we can add one extra burner to improve combustion capacity.

Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC) TS100(PLC)
Burn Rate 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour 100 kg/hour
Feed Capacity 20kg 40kg 60kg 100kg 200 kg
Control Mode PLC PLC PLC PLC PLC
Combustion Chamber 100L 210L 330L 560L 1200L
Internal Dimensions 50x50x40cm 65x65x50cm 75x75x60cm 100x80x70cm 120x100x100cm
Secondary Chamber 50L 110L 180L 280L 600L
Smoke Filter Chamber Yes Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual Manual
Voltage 220V 220V 220V 220V 220V
Power 0.5Kw 0.5Kw 0.5Kw 0.7Kw 0.7Kw
Oil Consumption (kg/hour) 5.4–12.6 7.8–16.3 10.2–20 12.1–24 14–28
Gas Consumption (m3/hour) 6.2–11.4 8–15.7 9.8–20 9.9–26.1 10–32.2
Temperature Monitor Yes Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes Yes
Oil Tank 100L 100L 100L 100L 200L
Feed Door 30x30cm 45x40cm 55x50cm 70x55cm 80x60cm
Chimney 3Meter 3Meter 5Meter 5Meter 10Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree
2nd. Chamber Temperature 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1500kg 2200kg 3000kg 4500kg 6000kg
External Dimensions 140x90x120cm 160x110x130cm 175x120x140cm 230x130x155cm 260x150x180cm

Pyrolysis Deemed a Viable Option to Incinceration


Researchers at the University of York have concluded that PyroPure (UK) technology has the potential to alter the way in which toxic waste is ruined in clinical surroundings and say pharmacists, hospitals and manufacturers across the UK should consider trialling the system.

The statement follows a six month Innovate UK-funded Knowledge Transfer Partnership project in which a team of leading scientists from the University’s Environment Department and Centre of Excellence in Mass Spectroscopy verified that the system helped destroy active pharmaceutical ingredients (APIs) found within pharmaceutical waste onsite.

A total of 17 of the very thermally resistant APIs were chosen for the trial, that demonstrated that PyroPure technologies destroys over 99 percent of APIs in 10 of the 17 examined and a mean of 94 percent of their’worst case’ pharmaceuticals. On the future of PyroPure as an alternative to high temperature incineration, he remarks:

“There are large concerns over the negative impacts of pharmaceuticals on the natural environment. Inappropriate disposal of pharmaceuticals and emissions from manufacturing sites are regarded as significant contributors to those impacts. Our work shows that PyroPure could help reduce the levels of pharmaceuticals in rivers and streams and have large benefits for ecosystem health. The system also supplies a variety of other environmental and economic benefits that could radically change how waste of this sort is accumulated and ruined going forward. With PyroPure technology, toxic waste and controlled substances no more have to be hauled throughout the nation to incineration facilities, thereby reducing the related costs, carbon emissions and dangers associated with moving waste from the point of origin to its point of disposal.”

Presently in the UK, pharmaceutical wastes are only disposed of in large scale, high-temperature incinerators, which can be up to 200 miles from where the waste is created. The Environment Agency has previously indicated that PyroPure, that is based on pyrolysis, a thermochemical decomposition procedure using high temperatures and a lack of oxygen, followed by catalytic conversion to clean and convert the gases, which may be the first viable option to high-temperature incineration for liquid wastes.

On the trial’s success, Peter Selkirk, PyroPure Ltd’s Executive Chairman, adds:”This is a huge step forwards for PyroPure technology as well as the healthcare industry. For too long now, we have been too determined by incineration as the only viable route to dispose of toxic waste. Not only can it be expensive but it’s also open to security breaches, especially when the waste has to be hauled long distances. Now PyroPure is a proven technology I’m convinced that this breakthrough will pave the way for a new method of waste disposal and irrevocably alter the version for waste collection in clinical environments throughout the world.”

The trial, that formed a Knowledge Transfer Partnership involving PyroPure Ltd and the University, also demonstrated how onsite energy recovery throughout the PyroPure procedure is at least 75 percent compared with 20 percent to get a high-temperature incinerator. The user simply opens the device’s lid and places the waste inside the chamber prior to initiating the process of pyrolysis to destroy it.

by: http://www.pollutionsolutions-online.com/news/hazardous-waste/20/pyropure_ltd/pyrolysis_deemed_a_viable_alternative_to_incinceration_according_to_uk_university/32282/

Each PyroPure unit is the size of a chest freezer. The user simply opens the unit’s lid and places the waste within the chamber before initiating the process of pyrolysis to destroy it.

by: http://www.pollutionsolutions-online.com/news/hazardous-waste/20/pyropure_ltd/pyrolysis_deemed_a_viable_alternative_to_incinceration_according_to_uk_university/32282/


Mayo employee charged for killing pets, trying to burn them at incinerator

A Mayo Clinic employee is scheduled to make his first appearance in Mower County District Court on Thursday after being charged with killing his two pets and attempting to burn the bodies at the Mayo Clinic incinerator.

Daniel Joseph Carlson, 61, of Grand Meadow, was charged Sept. 10 with two felony counts of overwork/mistreat animals-torture based on an incident that allegedly occurred on Aug. 21.

According to the criminal complaint, an unnamed motorist informed an Olmsted County deputy at 8:18 a.m. Aug. 22 that Carlson, who works at the Mayo Clinic Waste Management Incinerator, had brought in a dog and cat that he’d killed in order to burn the bodies. The motorist claimed that Carlson said he’d “beat the dog to death with a stick and shot the cat” before placing the carcasses in a Mayo Clinic freezer.

Since Carlson lives in Grand Meadow, the incident report was forwarded to the Mower County Sheriff’s Office on Aug. 25 for investigation; Sheriff Terese Amazi has expressed frustration that Olmsted County shared the incident with local media prior to sending her office the report in question.

During the ensuing investigation, Carlson told a Mower County deputy that he’d “had enough” with his pets urinating in his house and shot them both outside his home on Aug. 21. The cat had been experiencing “medical issues” for about a year and he’d been unable to house train his 5-year-old poodle, according to the criminal complaint.

Carlson told authorities that he put the dead animals in the incinerator’s freezer storage area. The deputy seized the animal’s bodies, which were stored in a black garbage bag, from the freezer as evidence.

On Aug. 26, the Austin Veterinary Clinic examined the dead animals. According to the criminal complaint, a single bullet wound was observed on each, but there was no other damage. The vet disposed of the bodies.

The Mayo Clinic released the following statement Tuesday on Carlson: “Mayo Clinic is aware of the charges and is fully cooperating with law enforcement. We cannot provide further comment on private, personnel issues, or issues involving legal proceedings in progress.”

If convicted, Carlson faces a maximum penalty of two years in prison and a $5,000 fine for each charge.

Contact Us


Nanjing Clover Medical Technology Co., Ltd.

Tel: +86-25-8461 0201

Fax: +86-25-8461 0406

Website: www.inciner8.cn

Email:  [email protected]

contact hiclover

Service Skype: clover-incinerator

Pусский: www.hiclover.ru

中文: www.haiwo.net

Photo Gallery: www.eclover.net

Clover News: www.incinerator.info

Facebook: www.facebook.com/hiclover

Twitter: twitter.com/hiclovercom

YouTube: youtube.com/c/IncineratorClover


Send Message by below contact form:

Contact Form




medical waste incinerator

Australian combustion engineering proprietary LTD MK 5 25kg/hour
dual chamber(LPG) incinerator or equal approved. incinerator
casing to be mild steel with 125mm refractory lining including
primary and secondary chamber, insulated draft section above
secondary chamber, package burners, digital temperature control
systems, ash rake and poke, second door in primary chamber,
manual loading chute, semi automated operated counter balanced
loading door with loading tray complete with stainless steel flue
recommended spare parts.

Pyrolytic Twin Chamber Incinerator Small Size : Burning Rate : 30-45 kg/hr ; Optimum Tons Ability : 400 kg



Items/Model

TS50( PLC)


Principle

Strong Waste Incineration

Burn Price

30-45 kg/hour

Control Mode

PLC( Programmable Reasoning Controller Heater)

Burning Chamber

560L

Inner Measurements

100x80x70cm

Secondary Chamber

280L

Smoke Filter Chamber

Yes

Feed Establishing

Manual

Voltage

220V

Oil Consumption (kg/hour)

Regular 13.3

Gas Intake (m3/hour)

***

Temperature Level Display

Digital Show

Temperature Level Degree Protection

Yes

Oil Storage Tank

800L

Feed Door

70x55cm

Chimney

5Meter

Smokeshaft Kind

Stainless-steel

1st. Chamber Temperature Level Degree

800 ℃– – -1000 ℃

second. Chamber Temperature Level

1000 ℃ -1200 ℃

Residency Time

2.0 Sec.

Gross Weight

4500kg

Exterior Measurements

230x130x155cm

HICLOVER – Medical Environmental




Waste Incinerators
Medical Waste Incinerator
Pet Animal Cremation
Solid Waste Incinerator

Tel:  +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.



2020-03-21



Medical Waste Incinerator


Basic Info.

Model NO.:medical waste incinerator design
Export Markets:Global

Product Description

Pyrolytic incineration technical is conventional waste treatment way for many decades. All around the world, in many countries, people anti incinerator because the incinerator will produce a large Dioxin in the smoke. “Dioxins” refers to a group of poisonous chemical compounds that share certain chemical structures and biological characteristics. Dioxins can be released to the environment through forest fires, backyard burning of garbage, particular industrial activities, and residue from beyond commercial burning of waste. Dioxins divide very slowly and previous releases of dioxins from the incinerators in hospitals, incinerators in unkraine, incinerators italy, incinerators lab scale, incinerators manufacturer china, incinerators producers, man-made and natural sources still exist in the environment. Anyhow, we have to remind this, that is large scale incineration pant, normally greater than 30 ton per day. This is a social issue, to examine and indicate ways in various angles from the general public, government, economic development, environmental protection, technology development, etc..

A Model animal crematory burning rate from 20-400kgs per hour. Heavy duty combustion room and suit for large animal cremation.  In post combustion chamber. Practically smoke and smell free.

Smoke Filter Chamber with filter brick, Virtually smoke and smell free after burning.

Italy original oil or gas burner, quality dependable. It suit for petrol oil, natural gas, LPG gas.

User guider, full installation and operation document for customer.

Items/Model A1500 A2400 A4000 A5500
Burning Rate *animal 90 kgs/Hr. 150 kgs/Hr. 200 kgs/Hr. 400 kgs/Hr.
Feed Capacity *animal 120 kgs 200 kgs 300 kgs 500 kgs
Equipment Weight 7000 kgs 8300 kgs 13000 kgs 16500 kgs
Primary Chamber (Liters) 1500 2400 4000 5500
Secondary Chamber (Liters) 500 1200 1500 1500
External Dimensions (cm) 240x170x380 260x220x420 320x220x460 360 x 220 x 475
Internal Dimensions (cm) 150x100x96 220x110x100 257x147x108 300 x 147 x 125
Oil Tank(Liters) 500 500 500 500
Door Opening (cm) 59 x 81 90 x 110 108 x 128 108 x 128
Chimney (M) 10 10 14 14
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES
