Little Size Waste Incinerator

Posted on by


Product Description

Application Scope  1.

As previously two rationale although not just above, we nevertheless utilize incinerators.

How you are able to discover reasonable incinerator for your regional site?  Incinerator isn’t a cheap equipment, generally the small scale version 's price around $5, 000usd per unit and big scale version 's price more than $50, 000usd per unit. Thus, before buy one unit incinerator, you have to make clear following items:  A, burn what? Incinerator is a incineration equipment, function is flame waste. So what kind of waste that you would like to cure?  B, small or big? This according to the waste output every day or the waste volume per feed time, like animal size.  C, fuel? Incinerator use oil or gas fuel, generally, gasoline fuel is light oil burner incinerator design, liquid incinerators, livestock cremation equipment manufacturer, livestock crematory equipment, livestock crematory system, cheaper than petroleum and also the smoke cleaner than petroleum gas version. But some neighborhood site don't have gasoline distribution system.  And other technology items, like power(220v, 380v), waste feed door kind, incinerator structure, etc..

Items/Model YD-10C YD-20C YD-30C YD-50C
Burning Rate (kgs/Hour) 10 kgs/Hr. 20 kgs/Hr. 30 kgs/Hr. 50 kgs/Hr.
Feed Capacity (kgs) 40 kgs 40 kgs 50 kgs 80 kgs
Equipment Weight 1200 kgs 1200 kgs 1800 kgs 2200 kgs
Primary Chamber (Liters) 200 200 250 400
Secondary Chamber (Liters) 140 140 140 140
External Dimensions (cm) 170x140x160 170x140x160 170x140x190 180x160x200
Internal Dimensions (cm) 55x55x65 55x55x65 55x55x85 70x70x85
Oil Tank(Liters) 50 100 100 150
Door Opening (cm) 38 x 48 38 x 48 38 x 48 45×55
Chimney (M) 5 5 5 5
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES

Modern Incinerators

Posted on by


Product Description

Key Attributes:  * All versions with Dual combustion chamber.  *based on sequence * High fever, long lifetime of incinerator.  * Free or minimum installation on site.  * High speed, from 10kgs to 500kgs per hour, up to 6ton per day.  * PLC Control Plane. *based on order  * New Design for pet animal cremation business.  * One year warranty on incinerator and parts in stock.

TS model PLC incinerator is newest design for waste treatment, include medical waste, animal cremation and other solid waste. This gear quality structural for kinds of website, like petrol, gas and gas incinerator 50 mph, diesel burner room, gas burner chamber incinerator, diesel burners, diesel cremation machines, diesel crematorium, ecological division, animal cremation bureaus, etc.. CLOVER Incinerator provide updated versions with dual combustion chamber and smoke filter chamber using refractory lines, along with the combustion chamber temperature up to 1200 deg C.

Items/Model TS50(PLC)
Burn Rate 50 kg/hour
Feed Capacity 100kg
Control Mode PLC
Combustion Chamber 560L
Internal Dimensions 100x80x70cm
Secondary Chamber 280L
Smoke Filter Chamber Yes
Feed Mode Manual
Voltage 220V
Power 0.7Kw
Oil Consumption (kg/hour) 12.1–24
Gas Consumption (m3/hour) 9.9–26.1
Temperature Monitor Yes
Temperature Protection Yes
Oil Tank 100L
Feed Door 70x55cm
Chimney 5Meter
Chimney Type Stainless Steel
1st. Chamber Temperature 800degree–1000degree
2nd. Chamber Temperature 1000degree-1200degree
Residency Time 2.0 Sec.
Gross Weight 4500kg
External Dimensions 230x130x155cm

100-150kgs Burning cost with Second burning to be usage in the health center

Posted on by



Oil tank with 2000Liters capacity

Items/Model

TS150( PLC)


Principle

Waste Incineration Therapy

Burn Rate

Requirement 100-150 kg/hour

Feed Ability

Standard 750kg/feeding

Control Setting

PLC( Programmable Thinking Controller Burner)

Text Steel

8mm thickness

Chamber Product

High Alumina Fire Brick Wall Surface, 1750 ℃ Rate

Paint for outside face

800 ° C Rate

Combustion Chamber

1570L

Interior Measurements

150x100x105cm

Added Chamber

750L

Smoke Filter Chamber

Yes

Feed Establishing

Guidebook

Voltage

210/230V 50/60Hz

Power

0.9 Kw

Oil Intake (Liter/hour)

Normal 14( D.O)

Gas Consumption (m3/hour)

***

Temperature Level Show

Digital Present

Temperature Protection

Yes

Oil Storage Tank

300L

Feed Door

80x60cm

Smokeshaft

10Meter

Smokeshaft Kind

Stainless-steel

1st. Chamber Temperature Degree

800 ℃–– – – -1000 ℃

second. Chamber Temperature Level Degree

1000 ℃ -1200 ℃

Residency Time

2.0 Sec.

Gross Weight

8500kg

Outside Measurements

300x160x280cm( without smokeshaft)


Waste Incinerators
Medical Waste Incinerator
Pet Animal Cremation
Solid Waste Incinerator

Tel:  +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.



hiclover incinerator 100-150kgs per hr

Posted on by



Model

YD-100


Burning Rate

100-150 kgs/hour

Key Burning Chamber

2000 Liters

Additional Combustion Chamber

500 Litres

Feed Mode

Guidebook

Voltage

220V/380V

Power

2.5 Kw

Fuel Kind

Diesel Oil

Heater

Italy Original

Oil Consumption (Diesel Oil)

Ordinary 28 kg/hour

Gas Consumption (Natural Gas)

***

Inner Measurements

180x115x98 centimeters (key chamber)

External Measurements

270x185x280cm (without chimney)

Temperature Screen

Yes

Oil Storage Tank Capacity( if oil fuel)

200 Litres

Door Opening

55 x 80cm

Chimney Size

6.0 Meters

Smokeshaft Kind

Steel

Devices Gross Weight

9000 kgs

Operation Technical Specifications

Key Chamber Temperature

800 ℃–– -1000 ℃

Second Chamber Temperature

1000 ℃ -1200 ℃

Residency Time

2.0 Sec.

Burning Performance

＞ 98%

Waste Lower Calorific Power

3500Kcal


HICLOVER – Medical Environmental


Waste Incinerators
Medical Waste Incinerator
Pet Animal Cremation
Solid Waste Incinerator

Tel:  +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.



2020-03-22



Municipal Waste Incinerator

Posted on by


Basic Info.

Model NO.:medical waste incinerators vs animal crematory
Export Markets:Global

Product Description

1.

2. We accept company duration: FOB/C&F/CIF word, by sea/train, complete container or bulk products. 1. FOB (Free on Board), the cost leave China port. 2. C&F (Cost and Freight), FOB cost and freight price. 3. CIF (Cost and Insurance and Freight), FOB cost and insurance fee and freight price.

3. Payment Term:  By sea: 50% deposit T/T (bank transfer) in advance, and 50% equilibrium T/T before sending day.  By Train: 100 percent T/T in advance.  Shipping Document & Packing: Typically, We provide (1)Bill of Lading (Way Bill), what's sample…(2)Commercial Invoice, (3)Packing List ONLY.  If any additional documents/certification and tag print/words on packaging material or documents which request by importer or local customs, whatever happen in China or oversea, should inform seller in advance and charge as real price. By way of instance, Fumigation Certification, embassy certificate, BV/SGS…Inspection, certificate of original (C/O), Type A, etc.. Buyer must to inform seller ahead of time and cover these price. Seller rescue all rights to postpone/cancel shipping waste incinerator China, waste incinerator dual chamber, waste incinerator produced by clover, waste incinerator manufacturer, waste incinerators manufacturers, wastewater incinerator, and request lost price cause this incident. If the importer local customs arrest/request punishment or other situation brought on by buyer error, Clover Medical rescue all right to request compensation/litigation. Thanks for your collaboration.

5. The major time is largely 3-6 weeks, depending upon the products and volume.  Guarantee: 1 year for the gear. We provide spare parts for maintenance, free charge within the first year along with also the delivery cost is on the buyer.  Insurance: Bear all risks of loss of or damage to the goods in the time they have passed the ship's rail at the named port of shipment. We proposal apply All Risks insurance under each contract. When buyer pickup goods at local site, must inspect carefully. If any damage occurred under insurance coverage, buyer must inform insurance company and Clover Medical Limited immediately. We’ll provide necessary aid.

8. Insurance: Bear all risks of loss of or damage to the goods from the time they have passed the ship's rail at the named port of shipment. We proposal apply All Risks insurance under each contract. When buyer pickup goods at local site, must inspect carefully. If any damage happened under insurance policy, buyer should inform insurance company and Clover Medical Limited immediately. We will provide necessary assistance.

Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC) TS100(PLC)
Burn Rate 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour 100 kg/hour
Feed Capacity 20kg 40kg 60kg 100kg 200 kg
Control Mode PLC PLC PLC PLC PLC
Combustion Chamber 100L 210L 330L 560L 1200L
Internal Dimensions 50x50x40cm 65x65x50cm 75x75x60cm 100x80x70cm 120x100x100cm
Secondary Chamber 50L 110L 180L 280L 600L
Smoke Filter Chamber Yes Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual Manual
Voltage 220V 220V 220V 220V 220V
Power 0.5Kw 0.5Kw 0.5Kw 0.7Kw 0.7Kw
Oil Consumption (kg/hour) 5.4–12.6 7.8–16.3 10.2–20 12.1–24 14–28
Gas Consumption (m3/hour) 6.2–11.4 8–15.7 9.8–20 9.9–26.1 10–32.2
Temperature Monitor Yes Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes Yes
Oil Tank 100L 100L 100L 100L 200L
Feed Door 30x30cm 45x40cm 55x50cm 70x55cm 80x60cm
Chimney 3Meter 3Meter 5Meter 5Meter 10Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1500kg 2200kg 3000kg 4500kg 6000kg
External Dimensions 140x90x120cm 160x110x130cm 175x120x140cm 230x130x155cm 260x150x180cm

Dual Chamber Incinerator available for sale 50-200kgs per hr( in supply).

Posted on by



We supply Double Chamber Incinerator with primary chamber size average 1570Liters and burnning rate 50kgs per hour,100kgs per hour,150kgs per hour,200kgs per hour.

the incinerators are now ready for shipping.

Contact with us for quick respond: +86-13813931455

Secret Product Listing per 01 collection

Trick Burning Chamber

Secondly Burning Chamber

Smoke Filter Chamber

Incinerator PLC Control Situation

Smokeshaft:10.0 Meters

*( upgrade to Stainless-steel, cost-free price)

Italy oil/gas burner: 02 devices

Oil Container (if oil gas): 300Liters

Items/Model

TS150( PLC)

Idea

Waste Incineration Therapy

Shed Rate

Criterion 50/100/150/ 200 kg/hour

Feed Capability

Average 750kg/feeding

Control Establishing

PLC( Programmable Thinking Controller Incinerator)

Combustion Chamber

1570L

Internal Dimensions

150x100x105cm

Second Chamber

750L

Smoke Filter Chamber

Yes

Feed Setting

Manual

Voltage

210/230V 50/60Hz

Power

0.9 Kw

Oil Usage (kg/hour)

Ordinary 20.4( D.O)

Thermal ability( kw/hour)

166-332

Gas Use (m3/hour)

***

Temperature Level Show

Digital Existing

Temperature Protection

Yes

Oil Storage Tank

300L

Feed Door

80x60cm

Smokeshaft

10Meter

Smokeshaft Kind

Stainless-steel

1st. Chamber Temperature Level

800 ℃–– – – -1000 ℃

secondly. Chamber Temperature Level

1000 ℃ -1200 ℃

Residency Time

2.0 Sec.

Gross Weight

8500kg

Exterior Dimensions

300x160x280cm( without smokeshaft)



animal incinerators china

Posted on by


Incinerate: medical waste and general waste Capacity to burn waste:

400-500kg/hr

Fuel: Diesel

Fuel Consumption: 10 liters/hr maximum

Incineration temperature: 950-1300 degrees centigrade

Casing: thick (min 5mm) stainless steel casing and fully insulated to

withstand sea humidity Voltage 220/240v or 380/415V Frequency 50Hz

Feeding: Automatic

Ash/leftovers removal: Automatic

Flue gas filtration system: Yes



Thus, please send me the full, detail technical & marketing documents and price list emphasis on the incinerators

portfolio and especially the no fuel incinerator with all detail things you have (All documents you sent me too short

cut and there is not any marketing color documents which pushed on my company’ marketing documents to offset print

early next week as planned).


50 Kg Per Hour Incinerator

Posted on by


Basic Info.

Export Markets:Global

Additional Info.

Trademark:clover

Product Description

Nanjing Clover Medical Technology Co., Ltd..

Items/Model YD-10C YD-20C YD-30C YD-50C
Burning Rate (kgs/Hour) 10 kgs/Hr. 20 kgs/Hr. 30 kgs/Hr. 50 kgs/Hr.
Feed Capacity (kgs) 40 kgs 40 kgs 50 kgs 80 kgs
Equipment Weight 1200 kgs 1200 kgs 1800 kgs 2200 kgs
Primary Chamber (Liters) 200 200 250 400
Secondary Chamber (Liters) 140 140 140 140
External Dimensions (cm) 170x140x160 170x140x160 170x140x190 180x160x200
Internal Dimensions (cm) 55x55x65 55x55x65 55x55x85 70x70x85
Oil Tank(Liters) 50 100 100 150
Door Opening (cm) 38 x 48 38 x 48 38 x 48 45×55
Chimney (M) 5 5 5 5
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Secondary Chamber  YES YES YES YES
Mix-Combustion Chamber YES YES YES YES
Smoke Filter Chamber YES YES YES YES
Combustion Fuel Oil/Gas Oil/Gas Oil/Gas Oil/Gas
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Temperature Monitoring YES YES YES YES

Application Scope:  1. Hospital& clinic: Iatric Waste, Infectious Waste, Dressing, Bio-Waste, Medicine.  2. 3. Laboratories, Remote Locations, Disaster Relief Operations, Animal Cremation
