HICLOVER Medical Waste Burner in Supply( Finished and Brand-new and semi-finished Production).
| Model | Capacity/Burnning Rate | For Hospital SickBed No. | Fuel Type | Qty. | Ready for Shipping | New Production | Shipping Volume | Shipping Weight | Delivery Location |
| TS30 | average 30kgs per hour | Average 150 SickBed | Diesel Oil | 1 set | 5 days | 20sets/2 weeks | 5 m3 | 3000 kgs | Shanghai Port |
| TS50 | average 50kgs per hour | Average 250 SickBed | Diesel Oil | 1 set | 7 days | 20sets/2 weeks | 7m3 | 4500 kgs | Shanghai Port |
| TS100 | average 100kgs per hour | Average 500 SickBed | Diesel Oil | 1 set | 7 days | 15sets/2 weeks | 10m3 | 6000 kgs | Shanghai Port |
| TS150 | average 150kgs per hour | Average 750 SickBed | Diesel Oil | 5 sets | 7 days | 15sets/2 weeks | 13m3 | 7500 kgs | Shanghai Port |
| YD10 | average 10kgs per hour | Average 50 SickBed | Diesel Oil | 2sets | 7 days | 20sets/2 weeks | 3m3 | 1200 kgs | Shanghai Port |
| YD20C | average 20kgs per hour | Average 100 SickBed | Diesel Oil | 2sets | 7 days | 20sets/2 weeks | 6m3 | 2000 kgs | Shanghai Port |
| YD50C | average 50kgs per hour | Average 250 SickBed | Diesel Oil | 2sets | 7 days | 20sets/2 weeks | 7m3 | 2300 kgs | Shanghai Port |
| YD30 | average 30kgs per hour | Average 150 SickBed | Diesel Oil | 1 set | 5 days | 20sets/2 weeks | 5m3 | 2300 kgs | Shanghai Port |
| YD30 Small | average 30kgs per hour | Average 150 SickBed | Diesel Oil | 2sets | 5 days | 20sets/2 weeks | 3m3 | 1500 kgs | Shanghai Port |
| YD50 | average 50kgs per hour | Average 250 SickBed | Diesel Oil | 2 sets | 5 days | 20sets/2 weeks | 8m3 | 4500 kgs | Shanghai Port |
| YD100 | average 100kgs per hour | Average 500 SickBed | Diesel Oil | 1 set | 10 days | 15sets/2 weeks | 13m3 | 6000 kgs | Shanghai Port |
| YD150 | average 150kgs per hour | Average 750 SickBed | Diesel Oil | 1 set | 10 days | 15sets/2 weeks | 17m3 | 7500 kgs | Shanghai Port |
| YD300 | average 300kgs per hour | Average 1500 SickBed | Diesel Oil | 10sets/2 weeks | 20m3 | 9000 kgs | Shanghai Port | ||
| YD500 | average 500kgs per hour | Average 2500 SickBed | Diesel Oil | 5sets/2 weeks | 27m3 | 13000 kgs | Shanghai Port | ||
| CA 50 Mobile Containerized | average 50kgs per hour | Average 250 SickBed | Diesel Oil | 2 sets | 15 days | 10sets/2 weeks | 28m3 | 7000 kgs | Shanghai Port |
| 1. Information High frequency change, for reference only. | |||||||||
| 2. Price as formal quotation and technical details and business term |
HICLOVER – Medical Environmental
Waste Incinerators
Medical Waste Incinerator
Pet Animal Cremation
Solid Waste Incinerator
Tel: +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.
2020-03-29
Heater Capacity of destruction of 350 kg/hour
common daily massacre entails 120 pigs. The Condemned item as well as also byproducts from the abattoir for Entry is around 1000 kgs.daily
1 line incinerator for the destruction of damaging clinical waste.
– – – – Heater capacity of damage of 350 kg/hour, calorific well worth of waste will certainly be 13-25 MJ/kg
[3,500 kcal/kg] along with ideal cozy ability 1,225,000 kcal/hr.
– – – – Burner damages ability will definitely be 8.4 tons/day and additionally procedure time will certainly be 24 human assets. / day.
-The temperature degree will certainly regulated in varying flow and also part in oxygen, burning gas is re-burned
from the re-combustion [additional] chamber at a temperature level of minimal 1,100 C throughout 2 secs.
– – – – Control board will certainly be fitted with an useful synoptic sight revealing the operating position of the entire
heater and handled by DCS/PLC system.
– – – – Gas treatment system will absolutely appreciate the EE standard [Directive 2000/76/EC -4/ 12/2000.
– – – – TOC of slag as well as bottom ashes will certainly be less 3 percent of the dry weight.
– – – – Deal will certainly be completely free of visible smoke.
– – – – Heater will certainly be made as a Packaged system, having electrical link pre-wired and continue pipelines
set up.
– – – – Incinerator will have automated de-ashing system with up direction.
– – – – Burner will surely have flue gas treatment system all-inclusive [emergency situation by-pass heap, gas cooling ,
2 activators as well as also particulates filtering method ] as well as assurance of releases from burner.
– – – – Training of AKU workers at website.
– – – – website could be assessed as well as likewise have a peek at present ATI maker, capability 150 kg/hr. In 1 day therapy.
– – – – Web site could be reviewed as well as likewise take a look at existing ATI manufacturer, capability 150 kg/hr. in 1 day treatment.
– – – – Existing facilities space is conveniently available in basement, 100′ ′ Size x 30 ′ large x 20 ′ Altitude for 2nd Incinerator.
– – – – Existing smokeshaft size is 12 meter, and also size is 24″ ″ dia.
Incinerator with Ease of destruction in weight: 60 Kg/h.
Capacity of jealousy in weight: 60 Kg/h.
it ought to be in a position to operate less than 10 hours/day
This incinerator needs to be able to destruct all combustible wastes generated by hospitals, private clinics, laboratories, institutes, etc…
Design Specification: Types A, B, C, D, and E of medical waste
“PYROLYTIC” combustion, by simply controlling the gasification of waste.
The incinerator should prevent the discharge of black smoke and fine dust, (Smokeless) throughout the loadings.
it ought to be able to decrease the volume of wastes from 98%.
it ought to be in a position to hold emission at the next burn with gas residence of less than 2 seconds.
The incineration must be wholly free of visible smoke as well as offensive odours.
The reduced volt electricity (L.C.P) of this waste will be 3,500 kcal/kg
The Temperatures of combustion: Minimum will be 850oC and max 1400oC
Post combustion: >1100oC.
The Inner diameter of the Chimney: Ø 400 and its own height: 8 m
The Loudness of the combustion room: 1.200 L
The Dimension of the door for loading in cm: 70×70.
Burner surgery ought to be Automatic On/Off
Gas: diesel
The supplier must supply necessary information for the top of the installment
This incinerator with”PYROLYTIC” combustion should contain:
A combustion chamber of waste:
* Perfectly tight door for the manual loading of waste. The loading must be Manual, Batch Load
* A burner of lighting which the usage is limited to the ignition of waste.
* Frontage of loading door seals ended up on hinges, wheel of screw plug, elastic joint, and stuffing insulating from refractory.
* The insulation of the combustion chamber ought to be composed of refractory bricks, so using a high content of aluminum and insulates bricks in order to assure a minimum temperature on the outside sheet metal.
* Composition of the refractory;
Refractory concrete:
. Nature: 42 percent of Al203
Insulate in panels that are fibrous:
. Thickness: ≥75 mm
Nature: Calcium silicate.
* Burner of lighting of waste, together with fuel, standard mono-bloc casting directing stirring flame, lighting and security of digital ignition, permanent ventilation, electromagnetic sluice gate of regulation and isolating valve.
* Plate of combustion in Carborundum, avoiding the fixing of glass and slags.
* Plate of combustion in Carborundum, avoiding the fixing of glass and slags.
Technical Design of Health Care Risk Waste Incinerator
Basic Info.
Product Description
Nanjing Clover Medical Technology Co., Ltd. Is a leading waste incinerator manufacturer in China. We are local manufacturer and one of the largest exporter of China. Pyrolytic incinerator equipment technical is main waste treatment all of the world, for Medical Waste, Animal Incineration, Pet cremation and suppliers of medical incinerator, supply and installation medical air in riyadh, supply of incinerator from china, swine incinerator dealers, syc -wwe 100, syc 20 clover medical, other Solid wste. The capacity from 10kgs/Hr. To 500kgs/Hr., up to 6ton per day. Presently, we supply different series for local customer requirements and design updated incinerator with our leading technology. The updated design feature of our range of incinerators make them one of the most cost effective in the world.
| Items/Model | YD-200 | YD-300 | YD-500 | YD-600 |
| Burning Rate (kgs/Hour) | 200 kgs/Hr. | 300 kgs/Hr. | 500 kgs/Hr. | 600 kgs/Hr. |
| Feed Capacity (kgs) | 400 kgs | 500 kgs | 800 kgs | 1100 kgs |
| Equipment Weight | 7600 kgs | 8300 kgs | 13000 kgs | 16500 kgs |
| Primary Chamber (Liters) | 2000 | 2400 | 4000 | 5500 |
| Secondary Chamber (Liters) | 500 | 1200 | 1500 | 1500 |
| External Dimensions (cm) | 270 x 185 x 380 | 260x220x420 | 320x220x460 | 360 x 220 x 475 |
| Internal Dimensions (cm) | 180 x 115 x 96 | 220x110x100 | 257x147x108 | 300 x 147 x 125 |
| Oil Tank(Liters) | 300 | 500 | 500 | 500 |
| Door Opening (cm) | 59 x 81 | 90 x 110 | 108 x 128 | 108 x 128 |
| Chimney (M) | 10 | 10 | 14 | 14 |
| Chimney Type | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| Secondary Chamber | YES | YES | YES | YES |
| Mix-Combustion Chamber | YES | YES | YES | YES |
| Smoke Filter Chamber | YES | YES | YES | YES |
| Combustion Fuel | Oil/Gas | Oil/Gas | Oil/Gas | Oil/Gas |
| Residency Time | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. |
| Temperature Monitoring | YES | YES | YES | YES |
Cremation Equipment to Medical Waste
Basic Info.
Product Description
| Items/Model | YD-30 | YD-50 | YD-100 | YD-150 |
| Burning Rate (kgs/Hour) | 30 kgs/Hr. | 50 kgs/Hr. | 100 kgs/Hr. | 150 kgs/Hr. |
| Feed Capacity (kgs) | 60 kgs | 150 kgs | 200 kgs | 300 kgs |
| Equipment Weight | 2300 kgs | 4000 kgs | 4300 kgs | 7000 kgs |
| Primary Chamber (Liters) | 360 | 900 | 1200 | 1500 |
| Secondary Chamber (Liters) | 200 | 200 | 500 | 500 |
| External Dimensions (cm) | 145x90x175 | 200x160x230 | 220x180x360 | 240x170x380 |
| Internal Dimensions (cm) | 100x60x60 | 120x90x85 | 130x100x90 | 150x100x96 |
| Oil Tank(Liters) | 200 | 300 | 300 | 500 |
| Door Opening (cm) | 48 x 60 | 62 x 80 | 55 x 80 | 59 x 81 |
| Chimney (M) | 5 | 5 | 10 | 10 |
| Chimney Type | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| Secondary Chamber | YES | YES | YES | YES |
| Mix-Combustion Chamber | YES | YES | YES | YES |
| Smoke Filter Chamber | YES | YES | YES | YES |
| Combustion Fuel | Oil/Gas | Oil/Gas | Oil/Gas | Oil/Gas |
| Residency Time | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. |
| Temperature Monitoring | YES | YES | YES | YES |
incinerator Model TS150
HICLOVER is growing brand for environmental protection field, and market share with most of Africa, Middle East, Southeast Asia countries and part of North America, Europe territory. We are trusted partner for governmental organizations, non-profit organizations, international contractors, logistics organizations, military, pet cremation business owners, etc. We have export experience more than 40 countries, including war zone like Iraq, Afghanistan, Somalia, South Sudan.
We are china incinerator manufacturer, contractor and exporter. Manufacturer make reasonable price for incinerator customer, supply medical incinerator, hospital incinerator, animal incinerators, hog incinerators, pet cremation equipment, small incinerator, pet incinerator, animal incinerator, portable incinerator, small animal incinerator, infectious waste pyrolysis machine, laboratory incinerator. HICLOVER help customer reduce purchase budget, custom made function, quality products and friendly service.Medical waste is posing a growing problem all over the world, jeopardizing the health of staff, patients, disposal workers and anyone else coming into contact with the often hazardous materials discarded by hospitals and other healthcare sites. Hospital waste varies from site to site and the biggest challenge is to dispose of this wide range of waste streams. Incineration is still the preferred way to process medical waste without endangering the heath patients, staff or anyone else coming into contact with them. Clinical waste is costing more and more to dispose of safely. Health Clinics and Health center can now handle their own waste streams using one of our specialist medical incinerators. Destroying hazardous waste at source is by far the most effective and efficient way of handling waste that could potentially spread diseases or viruses.
