Medical Dressing Incinerator
Basic Info.
Additional Info.
Product Description
Nanjing Clover Medical Technology Co., Ltd.
Key Attributes: * All Versions with Dual combustion chamber.
| Items/Model | YD-10C | YD-20C | YD-30C | YD-50C |
| Burning Rate (kgs/Hour) | 10 kgs/Hr. | 20 kgs/Hr. | 30 kgs/Hr. | 50 kgs/Hr. |
| Feed Capacity (kgs) | 40 kgs | 40 kgs | 50 kgs | 80 kgs |
| Equipment Weight | 1200 kgs | 1200 kgs | 1800 kgs | 2200 kgs |
| Primary Chamber (Liters) | 200 | 200 | 250 | 400 |
| Secondary Chamber (Liters) | 140 | 140 | 140 | 140 |
| External Dimensions (cm) | 170x140x160 | 170x140x160 | 170x140x190 | 180x160x200 |
| Internal Dimensions (cm) | 55x55x65 | 55x55x65 | 55x55x85 | 70x70x85 |
| Oil Tank(Liters) | 50 | 100 | 100 | 150 |
| Door Opening (cm) | 38 x 48 | 38 x 48 | 38 x 48 | 45×55 |
| Chimney (M) | 5 | 5 | 5 | 5 |
| Chimney Type | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| Secondary Chamber | YES | YES | YES | YES |
| Mix-Combustion Chamber | YES | YES | YES | YES |
| Smoke Filter Chamber | YES | YES | YES | YES |
| Combustion Fuel | Oil/Gas | Oil/Gas | Oil/Gas | Oil/Gas |
| Residency Time | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. |
| Temperature Monitoring | YES | YES | YES | YES |
Application Scope: 1. Hospital& practice: Iatric Waste, Infectious Waste, Dressing, Bio-Waste, Medicine. 2. 3. Community & Sea Port & Station: Municipal Solid Waste, etc. 4. Laboratories, Remote Locations, Disaster Relief Operations, Animal Cremation
Medical Waste Burner for Coronavirus Condition
Coronavirus Disease 2019 (COVID-19) pandemic continues all over the world, clinics,hospitals,goverment may need to consider on-site disposal for the infectious
medical waste. The medical waste incinerators that has been effectively used to dispose of hazardous waste during
viral outbreaks like Ebola. HICLOVER.COM reaches temperatures of up to 1200oC and is able to destroy health care waste
for laboratories, small clinics, and hospitals treating patients of the Novel Coronavirus (COVID-19) such as linens, sharps, gauze, gowns, etc.
medical waste incinerators manufacturers
chemical agents to be utilized:
10% heptyl (unsymmetrical dimethylhydrazine) water solution,
heptyl (unsymmetrical dimethylhydrazine) vapour with 0.8 to 1.0 kg/m3 concentration,
10% azotic (nitric) acid water solution,
azotic (nitric) acid vapour with concentration up to 1.1 kg/m3;
2. neutralization method: thermal decomposition;
3. neutralization temperature: +800?C to +1200?C;
4. performance:
? vapour capacity: 70 to 200 m3/h,
? water solution capacity: 50 to 500 l/h;
5. inlet pressure: up to 2 bars;
6. automatic control system;
7. overall dimensions shall allow for mounting the unit on a vehicle chassis.
medical waste incinerators manufacturers General Specifications
6mm plate steel sheel construction
11cm 1400 o C Refractory L iner
Temperature controlled Burners
Secondary combustion Burners
Interlock Switch on Load Doors
Separate Ash Door
One Second secondary Residence @ 1000 o C
400 ° C Silicone Based Paint Finish.
Alloy Temperature Sensor
Factory wired and tested
Capacity-20 kg / hr
Primary Chamber-1607 L
Hearth Area-1:36 sq. m
Secondary Chamber-694 L
Primary Burner (oil)-420,000 btu
Secondary Burner (oil)-900,000 btu
secondary Combustion-1/6 hp
Exhaust Stack-46cm x 6m
Electrical Service-220/50
Weight System-5.700 kg
Dimension “D”-152cm
Load Port Height- 60x 60 cm
Ash Port Height -36 x 36 cm
Incinerator A4000
Basic Info.
Additional Info.
Product Description
Key Features: * All versions with Dual combustion room. *according to sequence * High fever, long life of incinerator. * Free or minimal installation onsite. * High burn rate, from 10kgs to 500kgs per hourto 6ton per day. * PLC Control Plane. *according to order * New Design for pet animal cremation business. * One year warranty on incinerator and components in stock.
| Items/Model | A1500 | A2400 | A4000 | A5500 |
| Burning Rate *animal | 90 kgs/Hr. | 150 kgs/Hr. | 200 kgs/Hr. | 400 kgs/Hr. |
| Feed Capacity *animal | 120 kgs | 200 kgs | 300 kgs | 500 kgs |
| Equipment Weight | 7000 kgs | 8300 kgs | 13000 kgs | 16500 kgs |
| Primary Chamber (Liters) | 1500 | 2400 | 4000 | 5500 |
| Secondary Chamber (Liters) | 500 | 1200 | 1500 | 1500 |
| External Dimensions (cm) | 240x170x380 | 260x220x420 | 320x220x460 | 360 x 220 x 475 |
| Internal Dimensions (cm) | 150x100x96 | 220x110x100 | 257x147x108 | 300 x 147 x 125 |
| Oil Tank(Liters) | 500 | 500 | 500 | 500 |
| Door Opening (cm) | 59 x 81 | 90 x 110 | 108 x 128 | 108 x 128 |
| Chimney (M) | 10 | 10 | 14 | 14 |
| Chimney Type | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| Secondary Chamber | YES | YES | YES | YES |
| Mix-Combustion Chamber | YES | YES | YES | YES |
| Smoke Filter Chamber | YES | YES | YES | YES |
| Combustion Fuel | Oil/Gas | Oil/Gas | Oil/Gas | Oil/Gas |
| Residency Time | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. |
| Temperature Monitoring | YES | YES | YES | YES |
| 1st. Chmaber Temperature | 800degree–1000degree | 800degree–1000degree | 800degree–1000degree | 800degree–1000degree |
| 2nd. Chmaber Temperature | 800degree–1000degree | 800degree–1000degree | 800degree–1000degree | 800degree–1000degree |
Big General waste burner Burn Price as much as 250kg per hr
Items/Model
TS300( PLC)
Principle
Waste Incineration Treatment
Burn Price
Standard 250 kg/hour
Control Mode
PLC( Programmable Logic Controller Incinerator)
Combustion Chamber
2000L
Interior Dimensions
170x120x100cm
Secondly Chamber
1000L
Smoke Filter Chamber
Yes
Feed Setting
Handbook
Voltage
220V
Electricity
2.5 Kw
Oil Intake (kg/hour)
Average 28( DO)
Gas Intake (m3/hour)
***
Temperature Level Monitor
Digital Screen
Temperature Defense
Yes
Oil Storage Tank
1000L
Feed Door
80x60cm
Smokeshaft
10Meter
Smokeshaft Kind
Stainless Steel
1st.
800 ℃–– -1000 ℃
2nd. Chamber Temperature
1000 ℃ -1200 ℃
Residency Time
2.0 Sec.
Gross Weight
11000kg
External Dimensions
HICLOVER – Medical Environmental
400x210x300cm( with no smokeshaft)
Waste Incinerators
Medical Waste Incinerator
Pet Animal Cremation
Solid Waste Incinerator
Tel: +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.
An animal burner for the cremation of pets
We have a 70 mattress clinical center in namibia. There’s a potential of getting clients from many other regional physicians.
Can you please give me some information regarding these kind of incinerators (little variety ). It will surely be solitary utilization of every pet seperately.Initially we are getting ready to begin this Pilot Job with the National Medical center, to convince the Ministry Officials in addition to on its achievement to take this job to the Teaching Hospitals, Location and Base Hospitals from the Country.municipality demand 4 crematory apparatus for bodies. I want some information regarding cost, kine of electricity for detection, poisonous exhaust, The incinerator we are looking must be with the benefits of Cozy recycling system, usage of hot water, and so on.
Incinerator PLC
Basic Info.
Additional Info.
Product Description
Incinerator is a incineration equipment, direct fire squander by gas fuel or oi fuel. As distinct circumscription, incinerator could be named many words as below:
Treatment capacity: Small scale incinerator, big scale incinerator and incineration pant.
Waste material: Municipal waste incinerator, medical waste incinerator, animal cremation incinerator, individual cremators
Incinerator fuel: Gas incinerator, oil incinerator
Waste to Energy (WTE): WTE incinerator, non-WTE incinerator
Incinerator Manufacturer: China incinerator manufacturer, UK incinerator manufacturer, USA incinerator manufacturer, India incinerator manufacturer.
Famous Incinerator manufacturer firm: Inciner8(UK), Clover Incinerator(China), Pennram (USA), Haat (India)
Burning Speed: 5kgs/hour, 10 kgs/hour, 15 kgs/hour, 20 kgs/hour, 30 kgs/hour, 50 kgs/hour, 100 kgs/hour, 150 kgs/hour, 300 kgs/hour, 500 kgs/hour
PLC( Programmable Logic Controller), Intelligent and automated operation. Set combuston time according to different waste material and incinerator medical waste incinerators italy, medical waste incinerators maker, medical waste incinerators producers in china, medical waste incinerators manufacturers in usa, stop combustion . Establish temperature protection parameter, if the temperature overheat, incinerator stop combustion .
| Items | Specification | ||||
| Model | TS10(PLC) / TS20(PLC) / TS30(PLC) / TS50(PLC) / TS100(PLC) | ||||
| Main Product List | Double Combustion Chamber | ||||
| Smoke Filter Chamber | |||||
| PLC Mode Control Case | |||||
| Stainless Steel Chimney | |||||
| Italy oil/gas burner: 02 units | |||||
| Oil Tank (if oil fuel) | |||||
