Dual-chamber controlled air heater or dual- chamber pyrolytic heater

Posted on by



Types of burner style appropriate: Dual-chamber regulated air heater or double- chamber pyrolytic incinerator

Products of building: The incinerator shall not have any type of type of asbestos, asbestos-containing compounds, mercury thermostats, as well as additionally mercury switches. Refractory products shall have the capability to satisfy pertinent standards under ISO TC33 along with CEN/TC 187. Waste feed system right into the combustion chamber batch or consistent loading: For constant loading, the automatic payment ram or auger feed system shall be capable of instilling percentages of waste at normal periods in addition to should certainly have the capacity to prevent waste from being fed when the burning chamber temperature is much less than 850 ° C. In addition, the waste feed need to just be able opened up at or listed below 50 ° C in an ambient temperature level of 21 ° C.Primary burning chamber: Shall be built with a housing (reinforced to hold up against interior stress without deflection or damage to the various other or refractory aspects) supported by an architectural framework and provided with refractory cellular lining and also insulation
Ease of access doors, openings, and additionally spaces: All access doors, openings, and likewise spaces shall be sealed to stop discharge of smoke as well as exhaust gas and likewise to obstruct admission of air throughout burner procedures. Doors subjected to flame or direct warm of burning gases shall be lined with the specific same kind as well as likewise density of refractory mobile lining and insulation as that utilized in the burning chamber

Grate system for the primary chamber Transferring grate, taking a trip grate, reciprocating grate, or turning drum grate

Main combustion chamber temperature degree # 850 ° C without cool locations

Additional combustion chamber: Shall be created with an exterior case (reinforced to sustain internal stress and anxiety without deflection or damages to the refractory or different other components) along with used with refractory cellular lining as well as insulation

Secondary burning chamber temperature level 1100 ° C or higher

Second burning chamber house time # 2 seconds after the swan song of air in the second chamber



Smokeless Incinerators

Posted on by


Basic Info.

Export Markets:Global

Additional Info.

Trademark:clover
Origin:Nanjing

Product Description

Incinerator is a incineration gear, direct fire waste by gasoline fuel or oi gas. As distinct circumscription, incinerator could be termed many words as below:

Therapy ability: Small scale incinerator, big scale incinerator and incineration pant.

Waste material: Municipal waste incinerator, medical waste incinerator, animal cremation incinerator, human cremators

Incinerator gas: Gas incinerator, oil incinerator

Waste to Energy (WTE): WTE incinerator, non-WTE incinerator

Incinerator Manufacturer: China incinerator producer, UK incinerator producer, USA incinerator producer, India incinerator manufacturer.

Famous Incinerator maker company: Inciner8(UK), Clover Incinerator(China), Pennram (USA), Haat (India)

Burning Speed: 5kgs/hour, 10 kgs/hour, 15 kgs/hour, 20 kgs/hour, model: Syc-30 medical incinerator, model: Syc-10, versions for incinerator for biological waste, and modern double-chamber pyrolytic incinerators, modern incinerators in china, 30 kgs/hour, 50 kgs/hour, 100 kgs/hour, 150 kgs/hour, 300 kgs/hour, 500 kgs/hour

Please fill in following items and ship us back. We’ll study following important information and proposal our product versions, specification and so on.

Item Customer Request Example
Application Scope


 		 Hospital, Pet Crematory, Slaughter House, Laboratories, School, Community, etc. if for animal/pet, indicate animal size like: cat, dog, cattle, etc
What kind of waste?
____, _____%
____, _____%
____, _____%

Medical waste, dead animal, Municipal Waste, etc(detail name) or nature percent
if for animal/pet, indicate animal size like: cat, dog, cattle, etc
Quantity Request
01.02.03^..unit

Budget
$US Dollar.


Operating Time
The staff work Hours per day.
Our incinerator can work up to around 18 hours per day.
Realization Date of project In ___ year
Waste Output Capacity per Day?
 		 1000kgs Per Day^
Request waste burn rate   Capacity: 100kgs Per hour^
Request waste feed capacity   Capacity: 100kgs per feed^
Whether Natural Gas Supply Local?   Yes or No.
Local Power   If 380V and 220V valid?
Product Installation Destination
 		 Country or City name
DestinationSeaport name?   To check sea freight charge.

Customer
End-Customer, Agent, Government.

Method of contract   Tender or Negotiation
Date of Tender limit
How did you know our company?
Other request or information



INCINERATOR SPECIFICATION Capacity UPTO 20 kg/hr

Posted on by


Size:  940 x860x2700 mm
Material:  STAINLESS STEEL STACK, REFRACTORY CONCRETE LINING SPECIAL INSULATION MATERIAL
With burner:  15 C 20 KW
Temperature:   PRIMARY CHAMBER = 800°C AND SECONDARY CHAMBER = 850 – 1200° C
Sufficient heat generation for secure and complete combustion 600-800 °C in the first chamber and >1000 °C in the second chamber
Easy transportation on standard EURO-pallets
Constructed in a modular fashion  easy on-site movement and assembly with a minimum of equipment and technical skills;
For the destruction of problematic waste like sharps, amputates and body parts, wet or moist matter;
Off-gas quality: moderate smoke emissions during one quarter of the total incineration time; no visible emission during three quarters. AS PER INTERNATIONAL STANDARDS
The remaining ash approximately 5-10% in weight and below 1% in volume of the original waste AS PER INTERNATIONAL STANDARDS
Chimney height at least 5 m above the incinerator 5m ABOVE FROM THE GROUND
Temperature resistance of the lining  at least 1,200 °C


Incinerators – 2

Posted on by


Basic Info.

Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:CLOVER
Origin:Nanjing
Production Capacity:1000 Sets Per Year

Product Description

Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC) TS100(PLC)
Burn Rate 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour 100 kg/hour
Feed Capacity 20kg 40kg 60kg 100kg 200 kg
Control Mode PLC PLC PLC PLC PLC
Combustion Chamber 100L 210L 330L 560L 1200L
Internal Dimensions 50x50x40cm 65x65x50cm 75x75x60cm 100x80x70cm 120x100x100cm
Secondary Chamber 50L 110L 180L 280L 600L
Smoke Filter Chamber Yes Yes Yes Yes Yes
Feed Mode Manual Manual Manual Manual Manual
Voltage 220V 220V 220V 220V 220V
Power 0.5Kw 0.5Kw 0.5Kw 0.7Kw 0.7Kw
Oil Consumption (kg/hour) 5.4–12.6 7.8–16.3 10.2–20 12.1–24 14–28
Gas Consumption (m3/hour) 6.2–11.4 8–15.7 9.8–20 9.9–26.1 10–32.2
Temperature Monitor Yes Yes Yes Yes Yes
Temperature Protection Yes Yes Yes Yes Yes
Oil Tank 100L 100L 100L 100L 200L
Feed Door 30x30cm 45x40cm 55x50cm 70x55cm 80x60cm
Chimney 3Meter 3Meter 5Meter 5Meter 10Meter
Chimney Type Stainless Steel Stainless Steel Stainless Steel Stainless Steel Stainless Steel
1st. Chamber Temperature 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree
2nd. Chamber Temperature 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree 800degree–1000degree
Residency Time 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec. 2.0 Sec.
Gross Weight 1500kg 2200kg 3000kg 4500kg 6000kg
External Dimensions 140x90x120cm 160x110x130cm 175x120x140cm 230x130x155cm 260x150x180cm

PLC Incinerator (TS50 PLC)

Posted on by


Basic Info.

Model NO.:TS50 PLC
Pullution Sources:Solid Waste Processing
Processing Methods:Combustion
Export Markets:Global

Additional Info.

Trademark:Clover
Packing:Full Container
Standard:50 kg per hour
Origin:China
Production Capacity:1500 Units/Year

Product Description

Items/Model TS50(PLC)
Burn Rate 50 kg/hour
Feed Capacity 100kg
Control Mode PLC
Combustion Chamber 560L
Internal Dimensions 100x80x70cm
Secondary Chamber 280L
Smoke Filter Chamber Yes
Feed Mode Manual
Voltage 220V
Power 0.7Kw
Oil Consumption (kg/hour) 12.1–24
Gas Consumption (m3/hour) 9.9–26.1
Temperature Monitor Yes
Temperature Protection Yes
Oil Tank 100L
Feed Door 70x55cm
Chimney 5Meter
Chimney Type Stainless Steel
1st. Chamber Temperature 800–1000 degree
2nd. Chamber Temperature 1000-1200 degree
Residency Time 2.0 Sec.
Gross Weight 4500kg
External Dimensions 230x130x155cm

waste incinerator manufacturers china

Posted on by


5-1- Chambre de post combustion est installée au dessus du foyer  de combustion , elle  est constituée d’un

cylindre  métallique  revêtu intérieurement d’une couche d’ isolant et d’une couche de matériaux réfractaires.

5-2- Volume intérieur?: 2,1 m3

Est dimensionnée pour pouvoir  garantir  un temps de fumée de 2 secondes à 1100°C avec un pourcentage d’oxygène libre

d’au moins 6 %.

5-3 -Accessoires

?Trappe de visite boulonnée frontal pour permettre l’inspection périodique

?La liaison à la chambre de combustion est tapissée de réfractaire

?Installation les br?leurs

?Installation des sondes de mesure température

  1. PRODUCTION DE L’AIR COMBURANT DE LA CHAMBRE DE POST COMBUSTION

?Ventilateur centrifuge

?Tuyauteries  de distribution d’air

?Série  de vannes de distribution  d’air

?Soupape de régulation de l’air soufflé  asservi par la sonde du débit  d’ oxygène



  1. BRULEUR DE LA CHAMBRE DE POST COMBUSTION

Sont prévus 2 br?leurs du type à l’air soufflé au gasoil équipés  des dispositifs de sécurité.

A la mise en route du four les deux  br?leurs sont  allumés pour assurer la température minimale d’au moins 1100°C?;

ils restent en marche successivement  pour maintenir la température constante.

Puissance thermique installée (290 + 350) KW.



  1. CHEMINEE D’EVACUATION

Constitué par un conduit métallique vertical de 8 m de long installée au-dessus de la  chambre de PC, diamètre 630 mm

en t?le d’acier au carbone avec garnissage intérieur en réfractaire



  1. ARMOIRE ELECTRIQUE DE COMMANDE ET REGULATION

Composée  de?:

?Circuit  380 V- 50 HZ-3 phases

?Voyant sous tension

?Commande d’arrêt  général

?Voyant état des bruleurs

?Affichage des  températures  des deux chambres

?Minuterie des temps des cycles.

?Une variation des vitesses des ventilateurs

?Le tableau et les cablages sont prévus aux règles CEI avec protection IP 55

?Microprocesseur pour le contr?le et la régulation des températures, ainsi que les cycles d’opération

?Cablages réalisés selon les règles CEI.



  1. INSTRUMENTATION DE CONTROLE ET DE MESURAGE CONTINU

Les  dispositifs suivants  sont prévus?:

1)Thermocouples pour la mesure de la température  en chambre de combustion? et postcombustion, à la sortie de

l’échangeur dans la section d’entrée du filtre

2)Système de mesure de la concentration d’oxygène dans les fumées humides a la sortie de la chambre de postcombustion

constitué de?:

?Sonde de mesure de l’oxygène à l’oxyde de zirconium

?Pompe à la membrane

?débitmètre



An Incinerator is to be supplied by the Contractor on a rental basis at a location established by the Company. The

Contractor is to provide trained and competent personnel with initial installation, commissioning and operational

training under the supervision of the manufacturer’s technician. The incinerator is to be maintained and operated to

manufacturer’s specifications by trained personnel. Contractor must have sufficient personnel trained and competent to

operate the incinerator throughout the contract period. Specifications for the incinerator are attached in Appendix A.
